Lincoln Nautilus. Instrument Cluster Overview

  1. Status bar.
  2. Speedometer.
  3. Right information group.
  4. Fuel gauge.
  5. Engine coolant temperature gauge.
  6. Left information group.
Instrument Cluster
...

What Is the Tachometer. What Is the Speedometer. Fuel Gauge
What Is the Tachometer Shows the engine speed. The red line thickens where the engine speed enters the overspeed limiter. What Is the Speedometer Displays the vehicle speed. Fuel Gauge What Is the F ...
