Lincoln Nautilus: Exterior Lighting / Headlamps
Using the High Beam Headlamps
Push the lever away from you to
switch the high beam on.
Push the lever forward again or pull the lever toward you to switch the high beams off.
Slightly pull the lever toward you and release it to flash the headlamps.
Switching Headlamp Exit Delay On and Off
To switch headlamp exit delay on, pull the turn signal lever toward you after switching your vehicle off.
To switch headlamp exit delay off, pull the turn signal lever toward you again or switch your vehicle on.
Note: The headlamps turn off after three minutes with any door open or 30 seconds after the last door closes.
Headlamp Indicators
Lamps On
Illuminates when you switch the
low beam headlamps or the
parking lamps on.
Headlamp High Beam
Illuminates when you switch the
high beam headlamps on.
Exterior Lighting Control
Headlamps on.
Autolamps on.
Parking lamps on.
Lamps off.
Press the toggle switch upward or downward
to make a selection.
Note: The lighting control defaults to
autolamps each time you switch ...
Headlamps – Troubleshooting
Headlamps – Frequently Asked Questions
Why is there condensation in the headlamps?
Headlamps have vents to accommodate
normal changes in air pressure.
Condensation can be a natural
by-product of ...
